KB19

LiFePO4 230Ah Battery

  • LiFePO4 230Ah battery belongs to the GB 54173 series of dimension format

  • Upgrade from LFP205Ah and higher energy density under similar dimension with LFP205Ah

  • 230Ah LiFePO4 Cells series supports 1C charge and discharge rate.

  • 4000 times outstanding cycle life with maximum reliability.

  • Support cells with screw terminals and nut terminals

  • LiFePO4 230Ah battery is suitable for material handling equipment, commercial vehicles etcetera.


lifepo4 230ah battery
lifepo4 230ah battery
lifepo4 230ah battery
lifepo4 230ah battery
lifepo4 230ah battery
lifepo4 230ah battery

LiFePO4 230Ah Battery Technical Data


No.

Item

Specification

Note

1

Rated Capacity

230Ah

@1C

2

Nominal Voltage

3.2V


3

Actual Voltage Range

2.5-3.65V


4

Constant Discharge Current

≤230A

Typical Value=115A

5

Peak Discharge Current

≤460A

@60s

6

Constant Charge Current

≤230A

Typical Value=115A

7

Peak Charge Current

≤460A

@60s

8

Operating Temperature

Charge: 0℃~55℃
Discharge: -30℃~55℃


9

Storage Temperature

﹣30℃~60℃


10

Cell Dimensions

Thickness:53.82±0.5mm

Length:174.00±0.5mm

Height: 204.40±0.6mm


11

Cathode Material

LFP


12

Weight

4.09±0.12kg


13

Energy density

180Wh/kg


14

Cycle life

≥4000 times

@0.5C/0.5C 100%DOD

15

Terminal

Welding/Screw/Nut terminal



LiFePO4 230Ah Battery Terminal Options

LiFePO4 230Ah Battery Terminal Options

LiFePO4 230Ah Battery Dimensions

LiFePO4 230Ah Battery Drawing
LiFePO4 230Ah Battery Drawing
LiFePO4 230Ah Battery Terminal
LiFePO4 230Ah Battery Terminal

230ah LiFePO4 Lithium Battery Certifications

230ah LiFePO4 Lithium Battery Certifications
