KB19

LiFePO4 302Ah Battery

  • Belong to GB 71173 series of dimension format

  • Upgrade from LFP280Ah and higher energy density under similar dimension with LFP280Ah

  • 4000times outstanding cycle life with maximum reliability

  • Support 1C charge and discharge rate.

  • Support cells with screw terminals and nut terminals

  • The main application for material handing equipment, trucks,buses etcetera.


lifepo4 302ah battery 1
lifepo4 302ah battery 2
lifepo4 302ah battery 3
lifepo4 302ah battery 1
lifepo4 302ah battery 2
lifepo4 302ah battery 3

Technical Datas of LiFePO4 302Ah Battery


No.

Item

Specification

Note

1

Rated Capacity

302Ah

@1C

2

Nominal Voltage

3.2V


3

Actual Voltage Range

2.5-3.65V


4

Constant Discharge Current

≤302A

Typical Value=151A

5

Peak Discharge Current

≤604A

@60s

6

Constant Charge Current

≤302A

Typical Value=151A

7

Peak Charge Current

≤604A

@60s

8

Operating Temperature

Charge: 0℃~55℃
Discharge: -30℃~55℃


9

Storage Temperature

﹣30℃~60℃


10

Cell Dimensions

Thickness: mm

Length:173.93±0.3mm

Height: 204.59±0.5mm


11

Cathode Material

LFP


12

Weight

5.40±0.16kg


13

Energy density

180Wh/kg 357Wh/L


14

Cycle life

≥4000 times

@0.5C/0.5C 100%DOD

15

Terminal

Welding/Screw/Nut terminal




Terminals Option of LiFePO4 302Ah Battery

Terminals Option of LiFePO4 302Ah Battery

Dimensions of LiFePO4 302Ah Battery

DRAWING
DRAWING
TERMINAL
TERMINAL

Certifications of Lithium Battery

Certifications of Lithium Battery
Please Contact Lithium Storage!
Please Contact Lithium Storage!
