KB19

NCM102Ah Battery

  • Conform VDA 148 width of cell format

  • The basic lithium ion battery cells to produce NCM102AH-1P6S VDA 355module

  • NCM 523 with outstanding energy density appropriately 220Wh/kg

  • 2000times cycle life with maximum reliability.

  • Continuously improved energy density though nickle proportion promoting and light weighting technology.

  • Suitable for passenger vehicles and vehicles with limited space etcetera.


ncm 102ah battery 1
ncm 102ah battery 2
ncm 102ah battery 3
ncm 102ah battery 4
ncm 102ah battery 1
ncm 102ah battery 2
ncm 102ah battery 3
ncm 102ah battery 4

Technical Datas of NCM102Ah Battery


No.

Item

Specification

Note

1

Rated Capacity

102Ah

@1C

2

Nominal Voltage

3.7V

@1/3C

3

Actual Voltage Range

2.8-4.3V


4

Constant Discharge Current

≤100A

Typical Value=33.3A

5

Peak Discharge Current

≤400A

@10s

6

Constant Charge Current

≤100A

Typical Value=33.3A

7

Peak Charge Current

≤300A

@10s

8

Operating Temperature

Charge: -20℃~55℃
Discharge: -30℃~55℃


9

Storage Temperature

﹣20℃~55℃


10

Cell Dimensions

Thickness:52.20±0.3mm

Length:148.90±0.3mm

Height: 95.80±0.5mm


11

Cathode Material

NCM 523


12

Weight

1.70±0.3kg


13

Energy density

218Wh/kg 506Wh/L


14

Cycle life

≥2000 times

@0.33C/1C 100%DOD,80%EOL

15

Terminal

Welding/Nut Terminal



Terminals Option of NCM102Ah Battery

Terminals Option of NCM102Ah Battery

Dimensions of NCM102Ah Battery

DRAWING
DRAWING
NUT TERMINAL
NUT TERMINAL

Certifications of Lithium Battery

Certifications of Lithium Battery
